Bentley Structural i XM

374 Bentley Structural v8i XM v8.11.05.50 Bentley Structural - expands MicroStation's capabilities when designing structures made of metal, wood or concrete. Design sections: KM, KMD. The range of profiles has also increased significantly. Now elements can be placed not only, as in TriForma, at two points, but along a given length (convenient when placing supports, piles and columns) and line. In addition, when placing elements, you can set automatic docking. The Place Steel X-Bracing and Place Steel K-Bracing tools help you quickly place braces. The Place Steel Members Framing Between tool will allow you to cover the space between two beams with a specified number of members or at a specified distance. Bentley Structural gives you the ability to interactively snap to grid nodes, MicroStation lines, and Structural elements. When setting up such a binding, it is indicated how long.
