CSoft Model Studio Power Line

971 CSoft Model Studio Power Line v2.00.00.014 Model Studio CS Power Line is a software package designed for calculating and issuing a set of documents for the design of overhead power lines of all voltage classes at the stages of construction, reconstruction and repair. Model Studio CS LEP works in AutoCAD 2007/2008/2009/2010/2011 and software that includes AutoCAD (AutoCAD Architecture, AutoCAD Civil 3D, AutoCAD MEP). Calculation of mounting booms and wire and cable tensions During the installation of supports, a mechanical calculation of wires and cables is performed in accordance with PUE-7. This takes into account not only the properties of the wire and climatic loads, but also the loads from fastening fittings, garlands and other equipment. The curve is modeled by a catenary equation, which makes it possible to increase the accuracy of calculation results - for example, the calcula
